A Complete, Compact Air Solution for Professional Applications
The KAESER 5C Compact 5HP Rotary Screw Compressor System with Integrated Dryer from Prime Industry Solutions is designed for users who need a dependable, quiet, and efficient air system that arrives ready to run. This all-in-one package includes a rotary screw compressor, refrigerated dryer, filtration, moisture management, and a 56.8 gallon receiver tank—making it ideal for operations where consistent air quality is essential.
Performance & Core Specifications
- Flow rate: 21 CFM at 125 psig, 17 CFM at 160 psig
- Nominal motor output: 5 HP
- Sound level: 70 dB(A)
- Compressed air connection: 3/4 inch NPT
- Receiver tank capacity: 56.8 gallons
Fully Integrated System Components
- Refrigerated dryer removes moisture to protect downstream tools and equipment
- KE coalescing filter ensures cleaner air with low pressure drop
- KCF oil/water separator simplifies condensate disposal
- Eco-Drain 30 demand drain reduces energy waste
- Ball valve and 3 inch flex hose for easy installation
- Filled with KAESER premium synthetic fluid—ready for immediate operation
Electrical Requirements
The KAESER 5C system supports both single-phase and three-phase installations, making it adaptable for small shops and industrial facilities alike.
| Voltage | Full Load Amps | Required Fuse | Required Wire Size |
|---|---|---|---|
| 208V / 3ph / 60Hz | 15 A | 20 A | 12 AWG |
| 230V / 1ph / 60Hz | 23 A | 40 A | 8 AWG |
| 230V / 3ph / 60Hz | 15 A | 20 A | 12 AWG |
| 460V / 3ph / 60Hz | 7.6 A | 10 A | 14 AWG |
Dimensions & Weight
- Dimensions: 38.625 inches L x 24.325 inches W x 58 inches H
- Weight: 639 lbs
Built for Reliability & Quiet Operation
With a noise level of just 70 dB(A), the KAESER 5C operates quietly enough for indoor placement without disrupting nearby workstations. Its high-efficiency rotary screw design ensures long service life, reduced heat, and consistent airflow—even under demanding operating conditions.
Ideal for Small Industrial & Workshop Environments
Whether supplying air to CNC machines, pneumatic tools, fabrication equipment, or assembly processes, the KAESER 5C delivers industrial-grade performance in a compact, easy-to-install footprint. Everything you need comes pre-assembled and pre-filled, so you can simply connect the system and begin work.
Choose the KAESER 5C Compact 5HP Rotary Screw Compressor System with Integrated Dryer from Prime Industry Solutions and enjoy a quiet, efficient, and long-lasting compressed air solution built for everyday professional use.
KAESER 5C Compact 5HP Rotary Screw Compressor System with Integrated Dryer
$5,099.00
The KAESER 5C Compact 5HP Rotary Screw Compressor System with Integrated Dryer, available from Prime Industry Solutions, is a complete turnkey air solution engineered for clean, stable, and energy-efficient compressed air delivery. Designed for workshops, light industrial environments, fabrication areas, and manufacturing stations, this system brings high-end performance to any facility needing dependable air output with minimal noise and maintenance.
Powered by a durable 5 HP motor and built with KAESER’s trusted rotary screw technology, the 5C system delivers 21 CFM at 125 psig and 17 CFM at 160 psig. The integrated refrigerated dryer, low-pressure-drop coalescing filter, oil-water separator, and Eco-Drain 30 work together to provide consistently dry, contaminant-free air.
With a compact footprint, a 56.8 gallon receiver tank, and voltage options for both single-phase and three-phase installations, the KAESER 5C Compact System provides plug-and-play simplicity without compromising industrial-grade reliability.
A Complete, Compact Air Solution for Professional Applications
The KAESER 5C Compact 5HP Rotary Screw Compressor System with Integrated Dryer from Prime Industry Solutions is designed for users who need a dependable, quiet, and efficient air system that arrives ready to run. This all-in-one package includes a rotary screw compressor, refrigerated dryer, filtration, moisture management, and a 56.8 gallon receiver tank—making it ideal for operations where consistent air quality is essential.
Performance & Core Specifications
- Flow rate: 21 CFM at 125 psig, 17 CFM at 160 psig
- Nominal motor output: 5 HP
- Sound level: 70 dB(A)
- Compressed air connection: 3/4 inch NPT
- Receiver tank capacity: 56.8 gallons
Fully Integrated System Components
- Refrigerated dryer removes moisture to protect downstream tools and equipment
- KE coalescing filter ensures cleaner air with low pressure drop
- KCF oil/water separator simplifies condensate disposal
- Eco-Drain 30 demand drain reduces energy waste
- Ball valve and 3 inch flex hose for easy installation
- Filled with KAESER premium synthetic fluid—ready for immediate operation
Electrical Requirements
The KAESER 5C system supports both single-phase and three-phase installations, making it adaptable for small shops and industrial facilities alike.
| Voltage | Full Load Amps | Required Fuse | Required Wire Size |
|---|---|---|---|
| 208V / 3ph / 60Hz | 15 A | 20 A | 12 AWG |
| 230V / 1ph / 60Hz | 23 A | 40 A | 8 AWG |
| 230V / 3ph / 60Hz | 15 A | 20 A | 12 AWG |
| 460V / 3ph / 60Hz | 7.6 A | 10 A | 14 AWG |
Dimensions & Weight
- Dimensions: 38.625 inches L x 24.325 inches W x 58 inches H
- Weight: 639 lbs
Built for Reliability & Quiet Operation
With a noise level of just 70 dB(A), the KAESER 5C operates quietly enough for indoor placement without disrupting nearby workstations. Its high-efficiency rotary screw design ensures long service life, reduced heat, and consistent airflow—even under demanding operating conditions.
Ideal for Small Industrial & Workshop Environments
Whether supplying air to CNC machines, pneumatic tools, fabrication equipment, or assembly processes, the KAESER 5C delivers industrial-grade performance in a compact, easy-to-install footprint. Everything you need comes pre-assembled and pre-filled, so you can simply connect the system and begin work.
Choose the KAESER 5C Compact 5HP Rotary Screw Compressor System with Integrated Dryer from Prime Industry Solutions and enjoy a quiet, efficient, and long-lasting compressed air solution built for everyday professional use.
In stock
- Free shipping on all orders to USA & Canada
- No hassle returns, 30 days return policy
- Custom Colors & Options available upon request
